LED SL Panel 200B
(Bi-Color)
Identity No. : LM0200LP
Max. Capacity: 200W
Voltage: 18 - 28V DC
Current: 8A @24V
Color Temp.: Adjustable 2700K - 5600K
CRI: >95
TLCI: >95
Dimming: 0 - 100%
Control Signal: DMX 512
DMX Channel: 2
LED Life: Approx. 30,000Hrs
Stirrup: Ø28mm (1-1/8 in.) Socket
Class / IP Rating: 1 / IP 21
Max. Surface Temp.: 60 ºC
Max. Ambient Temp.: 45 ºC
Min. Distance to Illuminated Object: 1 m
Min. Distance to Flammable Object: 0.5 m
Operating Range: +90º ~ 0º ~ -90º
Weight (Lamphead): 9.0 kg
LED SL Panel 100B
(Bi-Color)
Identity No. : LM0100LP
Max. Capacity: 100W
Voltage: 18 - 28V DC
Current: 4A @24V
Color Temp.: Adjustable 2700K - 5600K
CRI: >95
TLCI: >95
Dimming: 0 - 100%
Control Signal: DMX 512
DMX Channel: 2
LED Life: Approx. 30,000Hrs
Stirrup: Ø16mm (5/8 in.) Socket
Class / IP Rating: 1 / IP 21
Max. Surface Temp.: 60 ºC
Max. Ambient Temp.: 45 ºC
Min. Distance to Illuminated Object: 1 m
Min. Distance to Flammable Object: 0.5 m
Operating Range: +90º ~ 0º ~ -90º
Weight (Lamphead): 4.6 kg
